How to measure your pickup box
position the tape measure's tang flush against the bulkhead. if you have a partner, have them hold the tang in position as you stretch the tape measure along the bed rail to the inside edge of the top of your tailgate. Record this measurement in your preferred units.
Ford Ranger
| Advertised Length | Length (Inches) | Width Between Wheelhouses (Inches) | Depth (Inches) |
|---|---|---|---|
| 5’ | 59.6” | 44.8” | 20.8” |
Ford F-150
| Advertised Length | Length (Inches) | Width Between Wheelhouses (Inches) | Depth (Inches) |
|---|---|---|---|
| 5.5’ | 67.1” | 51.1” | 21.4” |
| 6.5’ | 78.9” | 51.1” | 21.4” |
| 8’ | 97.6” | 51.1” | 21.4” |
Ford Super Duty (F-250, F-350)
| Advertised Length | Length (Inches) | Width Between Wheelhouses (Inches) | Depth (Inches) |
|---|---|---|---|
| 6.75’ | 81.9” | 50.5” | 21.2” |
| 8’ | 98.1” | 50.5” | 21.2” |
Chevy Colorado/GMC Canyon
| Advertised Length | Length (Inches) | Width Between Wheelhouses (Inches) | Depth (Inches) |
|---|---|---|---|
| 5’ | 61.7” | 45.5” | 20” |
Chevy Silverado/GMC Sierra 1500
| Advertised Length | Length (Inches) | Width Between Wheelhouses (Inches) | Depth (Inches) |
|---|---|---|---|
| Short | 69.9” | 50.6” | 22.4” |
| Standard | 79.4” | 50.6” | 22.4” |
| Long | 98.2 | 50.6” | 22.4” |
Chevy Silverado/GMC Sierra HD (2500, 3500)
| Advertised Length | Length (Inches) | Width Between Wheelhouses (Inches) | Depth (Inches) |
|---|---|---|---|
| Standard | 82.3” | 51.9" | 21" |
| Long | 98.2" | 51.9" | 21" |
RAM 1500
| Advertised Length | Length (Inches) | Width Between Wheelhouses (Inches) | Depth (Inches) |
|---|---|---|---|
| 5’7” | 67.4” | 51" | 21.5” |
| 6’4” | 76.3” | 51” | 21.5” |
RAM HD (2500/3500)
| Advertised Length | Length (Inches) | Width Between Wheelhouses (Inches) | Depth (Inches) |
|---|---|---|---|
| 6’4” | 76.3” | 51" | 20.2” |
| 8' | 98.3” | 51” | 20.2” |
Toyota Tacoma
| Advertised Length | Length (Inches) | Width Between Wheelhouses (Inches) | Depth (Inches) |
|---|---|---|---|
| 5' | 60.3” | 44.7" | 21.2” |
| 6' | 73.5” | 44.7” | 20.2” |
Toyota Tundra
| Advertised Length | Length (Inches) | Width Between Wheelhouses (Inches) | Depth (Inches) |
|---|---|---|---|
| 5.5’ | 65.6” | 48.7” | 20.9” |
| 6'5' | 77.6” | 48.7” | 20.9” |
| 8.1’ | 96.5” | 48.7” | 20.9” |
