Designed, tested and manufactured in Ontario, Canada.
Evenly Distributed Capacity: 350 pounds dynamic and 900 pounds static, or OEM Bed Rail capacity, whichever is less.
Mounting hardware for factory accessory rails (Jeep Trail Rail) included. Where accessory rails don't exist, bolts and lock nuts are supplied which require 4 bolt holes to be drilled through the inner bed rail. Alternatively, you can add no-drill clips to your order if you prefer a clamp on option.
41″ Rack Length – shorter length can make installation with a tonneau cover easier in some cases
45″ Rack Length – will fit all Gladiators
Load bar spacing:
41" rack - 34-1/2" inside and 40-1/2" outside
45" rack - 38-1/2" inside and 44-1/2" outside
Our Elite Series Bed Rack will work with INSIDE mounted tonneau covers that do not sit on top of the bed rail.
Self-adhesive foam weatherstripping should be added between the bed rails and the tonneau rails to help seal the gap created by the rack brackets.
Our most recommended tonneau cover to pair with our bed rack is the Truxedo Pro X15
**Important note: the brackets used are 3/16″ thick. Ensure you have enough space to mount under the tonneau cover rails. Minor modifications may be required (trim plastic rail caps, etc).
Or add our tri-fold brackets to accomodate over-the-rail tonneau covers. These brackets add 2.5" to the overall height of the bed rack.
